Chemical Plant Maintenance Platform Anti-Skid Platform Steel Grating

Platform Steel Grating Product Introduction

Platform Steel Grating Is the most commonly used steel grid plate in the most widely used products, steel grid plate welded after galvanized, not only beautiful appearance, but also can play a good role in anticorrosive and rust prevention, prolong the service life, by the majority of customers.

Hot dip galvanized steel grid plate is characterized by: high strength, light structure;The solid grid pressure welding structure makes it has the characteristics of high load bearing, light structure, easy to hoisting and so on;Beautiful appearance, durable.

Acid and alkali corrosion ability: in the range of pH 6 to pH 12.5, the zinc layer surface formed a stable protective film, good corrosion resistance.

Platform Steel Grating Product Specifications

Rod spacing: 50, 100mm.

Bar size: commonly used 6x6mm twisted square steel, small specification steel grid to take 5X5mm twisted square steel, stainless steel commonly used diameter of 5mm round steel.

Flat steel size: commonly used 20×3mm to 75×6mm and other specifications.

Flat steel spacing: 30mm, 40mm, 60mm.

Surface treatment: G for hot dip zinc, P for dip paint.

Platform Steel Grating Product Application

The application scope of platform steel grid, general factories, coal mines, offshore drilling platforms, oil refineries, vinyl plants, power plants, coal mines, power stations, workshops, ships and all kinds of natural gas chemical platform can be selected, beautiful and durable, easy installation, is a new type of building products to update.By welding Angle iron and hinge on the frame of the steel grid on the platform, many special occasions can be used, such as the cover plate of the air outlet and the trench.

Platform Steel Grating Product Advantages

1. Hot dip galvanized steel grille: it is through the physical reverse so that the inserted grille plate is coated with zinc layer, with beautiful products, acid resistance, alkali resistance, corrosion resistance, rust prevention, long service life and other characteristics, suitable for outdoor.

2. Electric galvanized steel grille: it is made by chemical reaction to form a thin layer of zinc through the plasma exchange of the platform steel grille plate, suitable for dry environment, such as indoor, etc.

3. Spray-painted steel grille plate: corrosion resistance medium, moderate price, color can be optional and other characteristics.

4. Don't handle steel grille plate: cheap price, suitable for indoor and dry environment, but in wet and rainy environment is easy to rust.

Platform Steel Grating Installation Method

Steel grid plate in the welding installation is generally fixed at the four corners of the steel grid, using the form of pull welding welding, weld length shall not be less than 20mm, height shall not be less than 3mm, for a single large area of steel grid plate, should be appropriate to increase the welding position, in order to increase the rigidity of the steel grid.
The welding position is better on the inside of the first bearing flat steel, so that the welded steel grid looks beautiful, safe and reliable.
Because when welding steel plate damage on the surface of the coating, advice immediately after the completion of the steel plate welding to anti-corrosion coating anticorrosive paint, due to the spraying antirust paint adhesion is far worse than at the beginning of anticorrosive coating adhesion, so steel case board installation is complete to regularly check whether antirust paint falls off, in the event of loss, carries on polishing processing should immediately,
After finishing the polishing and then spraying, this will greatly extend the service life of the steel plate, the welding will not corrode, but also relatively increase the safety factor.
The steel grid plate installed by welding is suitable for one-time fixing and does not need to be disassembled twice. The welding fixing cost is low and the installation speed is fast, so it is a common installation method.

Package delivery:


Delivery when will we have a professional inspectors to check the quality of the product is unqualified, such as qualified will paste the qualified product certificate, and then fixed by shipping packaging, packaging with the steel plate on the metal tray, and then fixed with metal packing tape, finally wrapped by plastic film packaging, general each pallet packing 1-2 tons of cargo, in order to convenient for unloading and storage after the arrival of the goods. The unqualified products will be recalled by our quality inspector.
